FVM Fork Viscosity Meter Emerson Micro Motion Coriolis Meter for Viscosity / Density measurement

FVM Fork Viscosity Meter Emerson Micro Motion Coriolis Meter for Viscosity and Density measurement

Quick Detail:

Rugged, accurate multi-variable measurement

Continuous, multi-variable measurement of

viscosity, density and temperature

Accurate measurement of viscosity(±1% of full

scale) and density (±1 kg/m

Optimized design – insensitive to vibration,

temperature and pressure variations

Superior multi-variable I/O, meter health, and

application capabilities

Hazardous-area approved, head-mounted

transmitter that supports local configuration and

display

Internal diagnostics for fast verification of meter

health and installation

Application-specific factory configurations

ensurefit-for-purpose operation

Installation flexibility and compatibility

Direct insertion design for pipeline, bypass loop

and tank installations

Unique direct insertion design in lengths of up to

4 m (13 ft)

Supports multiple protocols for connection to

DCS, PLC, and flow computers

Description:

Liquid viscosity is an important process parameter in applications as diverse as pipeline drag reducer injection, pump protection, turbine correction and fuel oil burner control. In many cases these processes require measurement of multiple variables including viscosity, density and temperature – all of which need to be fast-response and online. Process conditions and the liquid itself can make measurements challenging, whether it be due to high process temperatures and vibration levels or limited installation accessibility.

With Emerson’s Micro Motion Fork Viscosity Meter you get a fast-response, direct insertion multi-variable sensor that is capable of viscosity, density and temperature measurement in pipelines, bypass loops and tanks. The meter incorporates an innovative new integral transmitter that has extensive communications flexibility and can be factory pre-configured to your specific application, reducing your system integration and set-up costs. Maintenance burdens can also be minimized through a revolutionary new meter health diagnostic – Known Density Verification (KDV).

Applications:

Combustion Control

• Oil Fired Heater and Boiler Control Improved fuel atomization consistency with varying feed stock quality

• Maintenance and Emissions Reduced fiscal exposure through optimized maintenance cycles and reduced NOx /SO x levies

Refining & Petrochemical

• Product Detection and Quality Optimize product uniformity and consistency while minimizing manual sampling

• Product Blending Minimize cutter-stock costs for accurate multi-grade Heavy Fuel Oil (HFO) production

 Pipeline & Terminals

• Interface and Product Detection Improve cut-over accuracy and product quality determination to reduce scrap, waste or down-grading of multi-product pipelines

• Volumetric Flowmeter Viscosity Correction Improved inventory accuracy through reduced K-factor and volumetric flow errors

Specifications:

Competitive Advantage:

The Micro Motion Fork Viscosity Meter Delivers: Superior Measurement Capabilities

• A rugged, multi-variable direct insertion sensor that  provides the best, real-time measurement of viscosity (±1% of calibrated range max) and density (±1.0 kg/m3)

• Application flexibility with pipeline, bypass (fast) loop  and tank installation support A World-Class Leading Electronics Platform

• Local display and user interface that allows for a simplified device management, minimizing maintenance requirements

• Simple integration into DCS, PLC and flow computers  (Analog 4-20mA, HART, Modbus RS485 and FOUNDATION fieldbus)

• Revolutionary device diagnostics and verification methods Robust and Flexible Measurement

• Application-specific measurement and output  configurations to ensure simple set-up and commissioning

• Optimized design; insensitive to vibration, temperature  and pressure variations
